Laheq four-bedroom villa ground floor plan with kitchen, living, dining, media room, bedroom and MEP enclosure Visualisation of a Laheq coastal four-bedroom villa terrace with pergola, pool, lounge seating and garden
24283_Laheq Island Residential / Hospitality (Ultra-luxury island community)
Construction Documents (2024); phase opening 2028
Kaon intake Elevation 00-01 at 1:25, with 400A cut-out, split metered board, main earth terminal and duct entry Charters Mary Road building with metal cladding and brick towers, in blue-toned black and white
23347_Charters Mary Road Commercial / Low-Carbon
In Use
Frimley small power plan of a clean utility room with socket outlets, bed head units and circuit references Revit 3D view of the Frimley roof plant room with blue cable ladder and trays past plant and walkways
23314_Frimley Park Hospital Hospital
In Use
Pitsea small power plan of endoscopy rooms with socket outlets tagged with circuit references and revision clouds Revit 3D view of Pitsea small power layout, recovery rooms tagged with circuit references such as DB-01-04-PWR/15L1
25154_Pitsea CDC
In Progress
SCH Block D2 riser elevation with dimensioned distribution boards, IDNO cut-out and tray routes Revit 3D view of the SCH Block D2 riser with DB 8TPN, DB 12TPN and DB 6TPN boards and meter board
25140_Surrey County Hall (SCH) Residential / Heritage
In progress
Woolwich schematic extract with life safety panel board PB-SLS4 and main panel board MSB-A2 feeding smoke extract and firefighting lifts Woolwich cable pit section with a cable duct on a 2000mm radius sweep over 5800 and 100mm clearance to foundation soffit
25034_Woolwich Central Residential & Commercial
For Construction
HOL LV schematic extract of UPS panel board UPB-B2-01, 8-way, with mechanical interlock and UPS bypass notes Revit 3D view of the HOV basement level B2 with coloured containment, switch room AB2-014 and electrical room
26004_Holborn Viaduct Commercial Office
In progress
